10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood

Place of Origin : Sichuan, China

Brand Name : KINGTOOLS

Model Number : A/B/C/D/E/F/G/H/J/K/L/M/N/T

MOQ : 2

Price : $1.99-3.99

Shank Diameter : 1/4", 1/8", 1/2", 3, 6, 8 mm

Material : Tungsten Carbide

Head Diameter : 3-25 mm

Chipbreaker : Single/Double/Aluma/Diamond Cut

Head Length : 6-36 mm

Overall Length : 38-81mm

Recommended Grade : YG8, YG10X

Head Dia Tolerance : +0.3 to +0.5mm

Cutting Part Tolerance : +0.5 to 1.0mm

Shank Dia Tolerance : +0 to +0.04mm

Total Length Tolerance : +-0.1mm

Density : 14.95 g/cm3 (YG6)

Hardness (HRA) : 91 (YG6)

TRS (Mpa) : 1800 (YG6)

Product Process : CNC

Contact Now

Product Description

10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood

2.35mm 3mm 6mm 6.35mm 8mm 10mm 12mm 12.7mm 14mm 16mm 20mm 25mm Shank Dia Tungsten Carbide Rotary Files Burrs YG6 / YG8 / YG10x
Recommended Grade
YG8, YG10X for carbide head,steel for shank diameter.
Size Rage
Head dia 3-35mm;
Shank dia 3,6.8mm
Increase length are available.
Tolerence
Head diameter is +0.3 to +0.5mm;
Head cutting part is +0.5 to 1.0mm;
Shank diameter is +0 to +0.04mm
Totel length is +-0.1mm
Sets for carbide cutters.
3pcs/5pcs/6pcs/8pcs/10pcs/12pcs/14pcs in aluminum sets
3pcs/5pcs/6pcs/8pcs/10pcs/12pcs/14pcs in plastic sets
The items can be selectable according to client demand.
Applications:
Milling out Weld dressing Deburring Cutting out holes Surface work Milling Weld dressing
10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood
Product Details

10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood

Name Type Cut Material Product Process LOGO
Cylindrical Shape Burr A Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Cylindrical End Cut B Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Cylindrical Radius End C Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Ball Shape Burr D Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Oval Shape Burr E Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Tree Shape Radius End F Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Tree Pointed Ends Burr G Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Flame Shape Burr Burr H Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Cone Shape With 60° J Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Cone Shape With 90° K Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Taper Radius End Burr L Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Cone Burr M Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Inverted Cone Burr N Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Disc Type Burr W Standard/Single/Double/aluma Tungsten carbide/YG7/YG8 CNC available
Grades of Carbide Tungsten Burr
China Grade ISO grade Density(g/cm3) HRA TRS(Mpa)
YG6 K20 14.95 91 1800
YG6X K10 14.95 92 1800
YKM6A K10 14.95 92.5 1800
YG8 K30 14.7-14.8 90 1950
YT5 P30 13 90.8 1900
YT14 P10-20 11.5 91.5 1500
YT15 P10-20 11.3 91.8 1450
YW1 M10-20 13.1 91.5 1600
YW2 M10-20 13.1 91 1600
YS25 P25 12.8 91.5 1900
YC30S P30 12.8 91 2000
ZP35 P35 12.8 91 2000
YC40 P35 13.2 90 1850
10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood
Customized Service
10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood
Company Information

10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood

Packaging & Shipping

10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood

FAQ

10pcs Tungsten Carbide Burr Set 6mm 1/4 Shank Double Cut for Metal Wood

OEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide Burrs OEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide BurrOEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide BurrsOEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide BurrsOEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide Burrs OEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide Burrs OEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide Burrs OEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide Burrs OEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide Burrs OEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood Grinding Engraving Polishing Tungsten Rotary Burr Set Porting Tools Carbide BurrsOEM/ODM 10pcs 6mm 1/4'' Shank Dia Metal Wood
